Main Specifications
|
Model
|
Chisel Diameter
|
Suitable Carrier
|
Total Weight
|
Blow Frequency
|
Hydraulic Oil Flow
|
|
SB20
|
45 mm
|
1.2~3.0 ton
|
129 kg
|
700~1200 bpm
|
20~30 L/min
|
|
SB30
|
53 mm
|
2.5~4.5 ton
|
155 kg
|
600~1100 bpm
|
25~50 L/min
|
|
SB40
|
68 mm
|
4~7 ton
|
361 kg
|
500~900 bpm
|
40~70 L/min
|
|
SB43
|
75 mm
|
6~9 ton
|
450 kg
|
400~800 bpm
|
50~90 L/min
|
|
SB50
|
100 mm
|
10~15 ton
|
1007 kg
|
350 ~ 700 bpm
|
80~110 L/min
|
|
SB70
|
135 mm
|
18~26 ton
|
1898 kg
|
400~800 bpm
|
130~150 L/min
|
|
SB81
|
140 mm
|
20~30 ton
|
2004 kg
|
350~500 bpm
|
120~180 L/min
|
|
SB121
|
155 mm
|
28~35 ton
|
2968 kg
|
300~450 bpm
|
180~240 L/min
|
|
SB131
|
165 mm
|
30~45 ton
|
2916 kg
|
250~400 bpm
|
200~260 L/min
|
|
SB151
|
175 mm
|
40~55 ton
|
3902 kg
|
200~350 bpm
|
210~290 L/min
|
Our products range as bellowing:
Engine parts:
filter, gasket, cylinder block, valve, cyliner liner, piston, connecting rod, bearing, crankshaft, fuel pump, oil pump, injector, water pump, turbo charger, alternator…
Transmission parts:
gearbox, drive axle, drive shaft, half axle, bevel gear set, differential assy, main drive, wheel side reducer, brake caliper, brake disc, brake pad…
Hydraulic parts:
cylinder, gear pump, multi-way valve, steering pump…
Electric parts:
light, horn, sensor, switch, instrument…
Other parts:
pin, sleeve, bucket, teeth…
